Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 79
Operating concept
External devices –
ventilator (Medibus
X)
(see page 401)
Vent parameter display
setting (see page 415)
Parameter 1 (vent, paw)
Parameter 2 (vent, paw)
Parameter 3 (vent, paw)
Paw scale
Flow scale
CO
2 Scale
Vol scale
Color (vent, paw, CO2)
All parameters of the
Configure show all page
(see page 413)
External devices –
Anesthesia
workstation
(see page 401)
Agent parameter field
O2 parameter field
etCO2 parameter field
External devices –
CO
2
(see page 432)
CO
2 Scale
Color
External devices –
PV Loop
Loop draw
Paw scale
Vol scale
External devices –
FV Loop
(see page 437)
Loop draw
Flow scale
Vol scale
External devices –
Loops (see
page 437)
Loop draw
External devices –
BIS (see page 379)
Scale[uV]
BIS secondary parameter
External devices –
NMT (see
page 385)
Display temperature
Parameter Included settings
Alarm profile settings
Alarm system
settings
(see page 458)
All alarms paused
Show alarm limits
Cardiac bypass
OR Alarms
Alarm bar enabled
Alarm validation
Pacer detection mode
ASY/VF alarms
NIBP/SpO2 interlock
Config. (see
page 458)
Alarm volume and
tone settings
(see page 461)
Alarm type
Alarm priority (high,
medium, low or off)
Pulse tone volume
Attention tone volume
Alarm volume
Alarm attention tones
Show remote alarms
Code settings
(see page 464)
Continuous recording
Alarm volume off
Continuous NIBP mode
All alarms off
Screen profile settings
Auto display
settings
(see page 446)
Auto view mode
Waveforms
Layout (right/left)
Pressure overlap
Parameter boxes
Layout
Split screen
Mini trends
NIBP trend
Toolbar
Selected parameter priority
Parameter Included settings
