Operating concept
80 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
Configurable views
(see page 451)
Up to eight available,
configurable views
Config. buttons
(see page 452)
Button setup
Multi-tab split
screen (see
page 455)
Tab 1, Tab 2, or Tab 3
Screen system
settings
(see page 445)
Monitoring sweep speed
[mm/s]
Respiratory sweep speed
[mm/s]
Show parameter units
General profile settings
Anesthesia and BIS
graphical trend
Configuration order of
parameters
Open lung tool
Procedures profile settings
Wedge
(see page 317)
Scale
Sweep speed [mm/s]
Reference waveform
Analysis tool
(see page 169)
Parameter selection
Duration
Biomed profile settings
Bedside setup
(see page 473)
Airway adapter
Patient profile selection
Parameter Included settings
