6 Dräger Interlock 5000 / 7000
Description
Legend
1 Holster for handset
2 Protective case for handset (optional)
3LED
4 Air outlet
5 Down/Menu button
6 OK button
7 Mouthpiece
8 Expansion box connection
9 GPRS module connection
10 Control unit
11 Socket for plug connector on spiral cable
12 Camera connection
13 IR interface
14 Spiral cable
15 Socket for plug connector on spiral cable
2.2 Functional description
2.2.1 Dräger Interlock
®
5000/7000
Before starting a vehicle equipped with the Dräger Interlock
®
5000/
7000
1)
, the driver must provide a breath sample. The unit measures
the breath alcohol concentration and can (optionally) log to memory
the test result, the measured value, engine starts and notes about
manipulations and violations. The vehicle can only be started when the
measured breath alcohol concentration lies below a preset limit value.
The instrument will also ask (optional) for retests while driving.
2.2.2 Camera (available as an option)
The camera can be used to record photos of the text subject during
a measurement.
2.2.3 GPRS module (optionally available)
The GPRS module can be used to expand the device with additional
functionalities.
2.3 Intended use
The Interlock
®
5000/7000 is a breath alcohol measuring instrument
with a vehicle "immobilizer".
2.4 Approvals
The Interlock 5000/7000 has the following approval markings:
1) Interlock
®
is a registered trademark of Dräger.
NOTICE
The instrument is not a security device for automobiles and is
not a substitute for a vehicle immobilizer for theft protection.
i
i
Marking Product
10 R - 057310
Dräger Interlock 5000 / 7000
10 R - 036669
Interlock 7000 GPRS module
FCC, IC Interlock 7000 handset,
Interlock 7000 GPRS module
