Order List
Order List
Designation and description Order No.
Dräger PIR 3000 infrared gas transmit-
ter
Dräger PIR 3000
1)
connecting thread 3/4" NPT, type IDS 0001
1) Splash guard and calibration adapter belong to the scope of delivery.
68 11 080
Dräger PIR 3000 compl. set d
2)
connecting thread 3/4" NPT, type ITR 0010
2) The complete set includes the terminal box (68 11 161), the splash guard as well as the
calibration adapter, already preassembled.
68 11 180
Dräger PIR 3000 compl. set d CCCF
2)
connecting thread 3/4" NPT, type ITR 0010
68 12 505
Dräger PIR 3000
1)
connecting thread M 25 x 1.5, type IDS 0011
68 10 810
Dräger PIR 3000 compl. Set e
3)
connecting thread M 25 x 1.5, type ITR 0001
3) The complete set includes the terminal box (68 11 299), the splash guard as well as the
calibration adapter, already preassembled.
68 11 160
Dräger PIR 3000 compl. Set e2
4)
connecting thread M 25 x 1.5, type ITR 0002
4) The complete set includes the terminal box (68 11 159), the splash guard as well as the
calibration adapter, already preassembled.
68 11 270
Accessories/Spare parts
Splash guard 68 10 796
Calibration adapter 68 10 859
Gas exposure / process adapter 68 11 330
Dirt deflector 68 11 135
Assembly set e 68 11 427
Assembly set d 68 11 426
Pipe connection set (duct mount) 68 10 995
Magnetic rod 45 44 101
Terminal box design type Ex d
(flameproof enclosure, 3/4" NPT, Ø10.0 cm)
68 11 161
Terminal box in Ex e design
(increased safety, M25, 11.0 x 7.5 x 5.5 cm)
68 11 299
Terminal box in Ex e design
(increased safety, M25, 12.0 x 12.0 x 7.4 cm)
68 11 159
Cable gland set M20 68 11 323
Instructions for Use 90 23 812
Installation Instructions 90 23 813
