Dräger PIR 7000 Assembly Instructions

12
34
5a 5b
7
00133236.eps
A
B
153
±0,5
122,5
±0,3
9
±0,3
1
3
2
4
5
7
6
8
9
10
12
11
13
14
23
15
6
16
202221
18
19
17

Dräger PIR 7000 Specifications

General

Detection Principle	Infrared (IR)
Pressure Range	700 to 1300 hPa
Ingress Protection	IP66/67
Gases Detected	Hydrocarbons
Measurement Range	0 - 100 %LEL (Lower Explosive Limit) or 0 - 100 vol.%
Operating Temperature	-40 to +65 °C
Output Signal	4-20 mA
Housing Material	Stainless steel
Certifications	ATEX, IECEx, UL, CSA
Response Time	t90 ≤ 4 s
