www.dragino.com
DLOS8 LoRaWAN Gateway User Manual 5 / 47
1 Introduction
1.1 What is the DLOS8
The DLOS8 is an open source outdoor LoRaWAN Gateway. It lets you bridge LoRa wireless
network to an IP network via WiFi, Ethernet, 3G or 4G cellular. The LoRa wireless allows users to
send data and reach extremely long ranges at low data-rates.
The DLOS8 uses Semtech packet forwarder and fully compatible with LoRaWAN protocol. It
includes a SX1301 LoRaWAN concentrator, which provide 10 programmable parallel
demodulation paths.
DLOS8 has pre-configured standard LoRaWAN frequency bands to use for different countries.
User can also customized the frequency bands to use in their own LoRaWAN network.
DLOS8 can communicate with ABP LoRaWAN end node without LoRaWAN server. System
integrator can use it to integrate with their existing IoT Service without set up own LoRaWAN
server or use 3rd party LoRaWAN service.
