Digistat +2RF Transmitter
Thermostat
LP10RF Receiver
Dimensions 137mm x 96.5mm x 31.3mm --
Power supply 2xAA 1.5V alkaline batteries 24Vd.c. less than 65mA
Radio frequency 433 MHz 433 MHz
Radio signal range 30m typically. The range may be affected by the composition / density and
number of walls between the Digistat+2RF and LP10RF.
Temperature range 5°C to 32°C --
Ambient operating temperature 0°C to +40°C 0°C to +50°C
Humidity operating range 25 - 90% non condensing up to
45°C
30 - 95% non condensing up to 45°C
Class of operation -- II
Degrees of protection IP30 IP24
Control Accuracy +0.5°C @ 20°C Better than ±1 second per day @
25°C
Battery life (with alkaline batteries) approx. 2 years N/A
Battery back up time and date 10 years min. 10 years min.
Shortest switching period 1 minute 1 minute
Hot water pre-heat settings -- 3 ON / 3 OFF
Central heating settings 6 per day --
Energy Class IV = 2% (Acc. EU 811/2013, 812/2013, 813/2013, 814/2013)
Pollution Class 2 2
Software Class A A
Ball pressure test 90°C 90°C
Technical Data
Relevant EC Directives:
2006/95/EC Low Voltage Directive
2004/108/EC Electromagnetic Compatibility Directive
1999/5/EC R&TTE Directive
2006/66/EC Battery Directive
2011/65/EU RoHS Directive
Applied Standards:
EN60730-1; EN60730-2-7; EN60730-2-9
EN 300 220-2; EN 301 489-3
Pack Contents:
LP10RF Programmer / RF receiver
Digistat+2RF transmitter
Screws (x2)
Wall Plugs (x2)
Instructions
Batteries (x2) AA Alkaline
2 Installation & User Guide
06515086001 ISSC
