Dremel 3D20 - Functional Description and Specifications; Product Specifications; System and Software Requirements

FUNCTIONAL DESCRIPTION AND
SPECIFICATIONS
BUILDING
Extruder: Single extrusion
Extruder temperature: Up to 230°C (397°F)
Operating Interface: 3.5” full color IPS touch screen
Maximum Build Volume: 9” x 5.9” x 5.5”
(230mm x 150mm x 140mm)
Layer Thickness: 4 mil | 0.004 inches 100 microns |
0.10 mm
Filament Colors: See Dremel3D.com for color choices
SD Card: Up to 32GB in size (3D20 will not work with
SD cards larger than 32GB)
Internal Storage: 4GB
WEIGHT & DIMENSIONS
Weight (without spool): 8.8kg (19lbs 8oz)
Dimensions: 19.1” x 15.7” x 13.2” (485mm x 400mm
x 335mm)
FILAMENT
ONLY works with Dremel PLA lament
Filament: 1.75mm PLA
(Biodegradable/Renewable)
FILAMENT STORAGE
All polymers degrade with time. Do not unpack until
lament is needed. Filament should be stored at room
temperature: 16-29° C (60-85° F)
SOFTWARE
Dremel 3D20 comes with complimentary Dremel 3D
software for Windows and Mac OSX. This application
converts your 3D digital les into buildable les.
MINIMUM HARDWARE REQUIREMENTS
A PC with these minimum requirements will be required
to run the Dremel
®
3D Software
Processor: Multi-core processor - 2 GHz or faster per
core
System RAM: 2 GB
Screen Resolution: 1024x768
USB port
WINDOWS REQUIREMENTS
Dremel
®
Software runs on 32 and 64-bit Operating
Systems
Windows Vista or later
MAC OSX REQUIREMENTS
Dremel
®
Software runs on Mac OSX 10.8 or later
ELECTRICAL REQUIREMENTS
3D20 input rating: 120V, 60Hz, 1.2A
OPERATING ENVIRONMENT
Room Temperature: 16-29° C (60 - 85° F)
Level workspace
Dry workspace environment
WALL
15.7” (400mm)
19.1” (485mm) 13.2” (335mm)
8” (203mm)
8” (203mm)8” (203mm)
14” (356mm)
4
