3D20 RESOURCES
Resource Description Location
Quick Start
Guide
Provides
illustrated
walkthrough of
how to un-box
your 3D20 and
start building out
of the box.
Printed version of
the Quick Start
Guide is located
in the rectangular
component carton.
It is also available
on www.dremel3d.
com
3D20 Website Provides the
latest 3D20
software, product
information, and
customer support.
www.dremel3d.com
3D20
Customer
Support
Contact Dremel
for product
support,
maintenance, and
service.
Dremel 3D20
Software
Allows you to
upload, edit, and
build 3D les.
You can also
change device
settings and order
supplies.
Installed from
www.dremel3d.com
or from SD card
provided with the
Dremel 3D20.
GLOSSARY OF TERMS
Term Denition
Build Platform The at surface used by your Dremel
3D20 to build objects.
Build Platform
Clip
Clip located at the front of the build
platform base that is used to secure
the build platform in place.
Build Tape Adhesive tape similar to blue painter’s
tape that improves the consistency of
your objects and helps them stick to
the build plate surface.
Build Volume The three dimensional (3D) amount
of space that an object will use once
it is completed. Your Dremel 3D20
has a maximum build volume which
means that objects with a larger build
volume cannot be built unless they
are resized or broken objects with a
larger build volume cannot be built
unless they are resized or broken into
sub-objects.
Door Your Dremel 3D20 has a door located
on the front panel. This allows for
easy access to the build platform,
extruder, lament, and your objects.
This door is made with a transparent
material so you can monitor the
progress of your objects while keeping
the build environment stable.
Lid Your Dremel 3D20 has a removable
lid on the top. This allows for more
access to the build platform, extruder,
lament, and objects when necessary.
Limit Switch Switch that is activated by the motion
of the extruder or build platform when
the end of travel is reached.
Extruder An assembly that uses gears to
pull lament through the extruder
intake, heat the lament to the build
temperature, and push the heated
lament out of the extruder tip.
Extruder Fan A fan used to cool the outer assembly
of the extruder and gear motor.
Extruder Intake An opening located at the top of the
extruder where lament is inserted for
building.
Extruder Push
Lever
A lever located on the side of the
extruder that is used to loosen the
grip of the extruder gear motor.
Extruder Tip A nozzle located at the bottom of the
extruder where heated lament is
forced out for building.
Filament A threadlike strand of plastic material.
Filament Spool A cylindrical piece on which a long
strand of lament is wound for storage
and continuous use.
Filament Guide
Tube
A plastic piece that guides the
lament from the lament spool
through a passage in the outer
housing of your Dremel 3D20.
Leveling
Knobs
Knobs located under the build
platform base that are used to create
proper spacing between the extruder
tip and the build platform.
