Leveling Tool Calibrated leveling pad with detailed
markings and directions for use.
PLA A bioplastic derived from renewable
resources such as corn starch.
Needle Nose
Pliers
Common tool used to hold small
objects and to grab excess material
that may be too hot to touch directly.
Object
Removal Tool
A tool used to separate your objects
from the build platform.
SD Card A portable memory card used on
a wide array of devices such as
cameras.
Spool Holder A plastic piece located to the left of
the build platform inside your Dremel
3D20 build area that is designed to
hold a lament spool.
Spool Lock A plastic piece which locks the
lament spool to the spool holder.
This piece is inserted through the
center of the lament spool, into the
spool holder, and turned to lock.
Stepper Motor A brushless DC electric motor used
to drive the guide rails and extruder
gears.
.STL File A common digital le format used in
a wide range of 3D model software.
This le is created in 3rd party
3D software or downloaded from
Dremel3D.com.
.3dremel File Dremel’s digital le format that is used
by your Dremel 3D20 to properly
process models.
.G3Drem File A buildable le format compatible with
your Dremel 3D20.
Touch Screen Full color display that is touch
activated. It allows you to monitor
your Dremel 3D20 and objects while
also providing commands directly to
your Dremel 3D20 without the use of
a computer.
Unclog Tool A tool used to clear the extruder of
excess debris.
X-Axis Guide
Rails
A set of rails on either side of the
extruder that allow a stepper motor to
move the extruder to the left or right
side of the build area.
Y-Axis Guide
Rails
A set of rails on either side of the
build area that allow a stepper motor
to move the extruder to the front or
back of the build area.
Z-Axis Guide
Rails
A set of rails located at the back of
the build area that allow a stepper
motor to move the build platform up
or down.
