APPENDIX
SUPPORT
Before contacting us, check our online FAQs. Submit all support questions to www.dashdaq.com/forum. The forums are constantly
monitored, and will provide you with the fastest answers.
TECHNICAL SPECIFICATIONS
Display 4” COLOR TFT w/touch panel
Resolution 480 x 272 (QWVGA) w 24-bit color display
System Processor 240MHZ ARM9
Vehicle Bus Processor 48MHZ ARM7
RAM 64MB SDRAM
Flash 16MB Flash
Memory Expansion MMC/SD Card 128MB to 8GB+
Device I/O touch-panel, ambient light sensor, 16-bit stereo line-out, 1W speaker, USB device port, programmable
button
Vehicle I/O CAN, J1850VPW (GM Class 2), J1850PWM (Ford SCP), ISO9141, KWP2000
Expansion I/O (2) USB Host Ports, (2) RS232 Ports, (2) 0-5V 10-bit analog inputs
Add-on sensors Blackline GPS (up to 20HZ), 0-5V Wideband O2 Sensors, NMEA GPS, USB 3-axis Accelerometer, USB K-
Type Thermocouple
Operating temperature -35 to 85C
Operating voltage 6 to 30V
Current Draw 200mA at 100% backlight
Dimensions 4.6” x 2.75” x 1”
Weight 0.5LB
Operating System Linux
Warranty factory tested with 1 year warranty
Other Features Real Time Clock, locking connectors, factory tested, field upgradeable firmware
Mounting Pattern AMPS 4-HOLE standard
Package Contents DashDAQ, Vehicle Cable, USB Cable, Windshield Pedestal, CD-ROM, users manual
