Drive 15005LP - Technical Specifications; Bed Model Specifications; Component Shipping Details

9
TECHNICAL SPECIFICATIONS
15005LP 15004P 15003P
Overall Length 87.99" 87.99" 87.99"
Overall Width w/o Rails 36.22" 36.22" 36.22"
Overall Width w/Rails 38.58" 38.58" 38.58"
Length & Width of Mattress Deck 79.53" x 34.65" 79.53" x 34.65" 79.53" x 34.65"
Maximum Weight Capacity
350 lbs Patient Wgt/ 450lbs.
includes all accessories
350 lbs Patient Wgt/ 450lbs.
includes all accessories
350 lbs Patient Wgt/ 450lbs.
includes all accessories
Head Deck Angle 0°to 68° 0°to 68° 0°to 68°
Foot Deck Angle 0°to 30° 0°to 30° 0°to 30°
Height Range
9.5" - 22.5"
14.96" - 22.83" 14.96" - 22.83"
Under Bed Clearance 2.6" 5.9" 5.9"
Total Product Weight (lbs.) 169 161 156
Head End & Head Section 68 67 67
Foot End & Foot Section 101 94 89
Noise Level ≤65dB(A) ≤65dB(A) N/A
Electrical Requirements 120VAC,60Hz 120VAC,60Hz N/A
Rated Current Input 1.8A max 1.8A max N/A
Fuse Specication 2A 250V 2A 250V N/A
Duty Cycle T_On 2 Min / T_Off 18 Min T_On 2 Min / T_Off 18 Min N/A
Battery Backup N/A N/A N/A
Relative Humidity
15% to 93% relative humidity,
non-condensing
15% to 93% relative humidity,
non-condensing
15% to 93% relative humidity,
non-condensing
Recommended Storage &Ship-
ping Temperature
-22°F to +158°F -22°F to +158°F -22°F to +158°F
Recommended Operating Tem-
perature
41°F to 104°F 41°F to 104°F 41°F to 104°F
Atmospheric Pressure Range 700hPa to 1060hPa 700hPa to 1060hPa 700hPa to 1060hPa
Component
Item #
Description Shipping Weight
(lbs)
Length
(inch)
Width
(inch)
Height
(inch)
15005LP
15215P Headspring&Low Headboard F/15005LP 1/cv 74.8 44.1 8.1 37.4
15216P Footspring&Low Footboard F/15005LP 1/cv 101 47.4 10.2 37.4
15004P
15210P Headspring&Headboard,for 15004P & 15003P 1/cv 73.8 44.1 8.1 37.4
15212-LP Footspring&Footboard For 15004P,1/cv 102.3 47.4 10.2 37.4
15003P
15210P Headspring&Headboard,for 15004P & 15003P 1/cv 73.8 44.1 8.1 37.4
15211P Footspring&Footboard, for 15003P 1/cv 96.9 47.4 10.2 37.4
