Drivecon VF61 - VF61 V;S Flux Vector VFD Connection Diagram

1 [F] 2 [R] 3 [2ND] 4 [3RD] 5 [4TH] 6 [5TH]
F
R
2*4 3*4
5
MFO1 MFO2
P15
0V
MOCM
MOCP
18 [P15] 10 [0V]
LED INDICATORS
GRAY
BLUE
YLW
ORG
BROWN
VIOLET
WHT
RUN
RELAY
FAULT
RELAY
RUN STATUS RELAY FORM A CONTACTS PICK UP ON RUN CONTACTS SHOWN IN STOP CONDITION 2A @ 250VAC FAULT RELAY FORM C CONTACTS PICK UP ON FAULT CONTACTS SHOWN IN NO FAULT CONDITION 2A @ 250VAC
SOLDER PAD CONNECTIONS
TB1
WHT / GRAY
WHT / BLUE
WHT / YLW
22 AWG 300V HOOK UP WIRE DRIVE END TERMINATED WITH RING TERMINALS
14 AWG WIRE MAXIMUM
TRAVEL LIMIT
SWITCHES
IF REQUIRED
RED
BLK
WHT / BLK
WHT / RED
10561532 110V INPUT ISOLATOR
OR
10561533 24V INPUT ISOLATOR
MOUNTED INSIDE
VF6100 HOUSING
PROG OUTPUT 1 PROG OUTPUT 2
10 11 12 13 14 16 [ACN]
PROGRAMMABLE
OUTPUT NO.1
FORM C CONTACTS
2A @ 250VAC
PROGRAMMABLE
OUTPUT NO.2
FORM C CONTACTS
2A @ 250VAC
110 vac NEUTRAL
G G
R R R R R R R R R
17 [TL1]
Y
18 [TL2]
Y
REV.0 9-2-98 REV.1 10-9-98
SLOWDOWN LIMITS ADDED GENERAL CONNECTION DIAGRAM.
FWD SLOWDOWN
LIMIT
REV SLOWDOWN
LIMIT
7 [MFI1] 8 [MFI2] 9 [MFI3] 15
MFI1 MFI2 MFI3
10561532 110VAC INPUT SIGNAL ISOLATOR BOARD. 10561533 24VAC INPUT SIGNAL ISOLATOR BOARD FOR USE WITH FLUX VECTOR VF61V/S SERIES VFD CONNECTION DIAGRAM
REV.2 4/26/00
VF61V/S
SERIES
FLUX VECTOR
VFD MAIN
CONTROL
BOARD
17 [ESTOP] 13 [FWD] 14 [REV] 19 [MFI1] 20 [MFI2] 21 [MFI3] 22 [MFI4] 24 [MFI6] 26 [MFO1] 27 [MFO2] 30 [MFO COM] 25 [MFO CLAMP]
31 32 34 35 33
110 VAC CONTROL
SIGNAL INPUTS
RELAY CONTACT OR
SWITCH CLOSURE
110 vac HOT
RESET
23 [MFI5] RESET
ESTOP
ESTOP CONTACT SHOWN
IS AN EXTERNAL RELAY
THE ESTOP CONTACT
MAY BE N/O OR N/C.
THIS INPUT CAN BE PROGRAMMED
TO CAUSE AN ESTOP FOR EITHER
CONDITION
RESET IS A MOMENTARY
CONTACT CLOSURE TO RESET
A FAULT
USE WITH VF61V/S
REV.3 7/15/00
RELOCATED RESET INPUT
NOTE X
NOTE X: DO NOT MAKE ANY EXTERNAL CONNECTIONS IN PARALLEL WITH ISOLATOR PCB'S OUTPUT.
