VF6100 SERIES
STANDARD VFD
MAIN PCB
D61532 / D61533
MOUNTED UNDER FRONT
COVER OF VFD
4 - #6 METAL
SELF TAPPING SCREWS
AND NYLON WASHERS
THREADED INTO
PLASTIC STANDOFFS
MOLDED INTO
VFD HOUSING
