General
This installation manual must be used in conjunction with the control panel manual. All the safety instructions specified
within that manual must be observed. The control panel is referenced as the “panel” throughout this document. This install-
ation guide provides the basic wiring, programming and troubleshooting information.
This alarm communicator is a fixed, wall-mounted unit, and must be installed in the location specified in these instructions.
The equipment enclosure must be fully assembled and closed, with all the necessary screws / tabs, and secured to a wall
before operation. Internal wiring mustbe routed in a manner that prevents:
l Excessive strain on wire and on terminal connections,
l Interference between power limited and non power limited wiring,
l Loosening of terminal connections,or
l Damage of conductor insulation.
WARNING: Never install this equipment during a lightning storm!
Safety Information
The installer must instruct the system user on each of the following:
l Do not attempt to service this product. Opening or removing covers may expose the user to dangerous voltages or
other risks.
l Any servicing shall be referred to skilled persons only.
l Use authorized accessories only with this equipment.
l Do not stay close to the equipment during device operation.
l Do not touch the external antenna.
Model Information
This manual covers the following models of alarm communicators:
LTE - North America
Models TL280LER, TL280LE, LE2080R,and LE2080 support LTE bands B2, B4, B5, B12, B13 and WCDMA bands B2
and B5
LTE - Europe
Models TL280LE-EU, LE2080-EU support LTE bands 1, 3, 7, 8, 20, 28A, HSPA, bands 1, 3, 8, and 2G bands 3 and 8.
WCDMA - North and South America, Mexico
Models TL2803GRE, TL2803GE, TL280RE, TL280E, 3G2080RE, 3G2080E, TL2803GE-LAT, 3G2080E-LAT support
WCDMA bands B2 and B5 (850/1900MHz Operation).
LTE - LATAM and Mexico
Models TL280LE-LAT and LE2080-LAT support LTE bands 1, 2, 3, 4, 5, 7 and 28. WCDMA bands 1, 2, 4 and 5. 2G bands
2, 3, 5 and 8.
LTE - Australia and New Zealand
LTE Bands 1, 3, 5,8,9,18(26),19 and 28. WCDMA Bands 1, 5, 6, 8 and 19.
NOTE: Only models TL2803GE and 3G2080E are CNC certified for use in Argentina.
WCDMA - Australia, New Zealand and Brazil
Models TL2803GRE-AU, TL2803GE-AU, TL280RE-AU,TL280E-AU, 3G2080RE-AU, 3G2080E-AU support WCDMA 850
/ 2100 MHz.
Table 1: LTE North America - LE910-NA1
Band Transmit Band (Tx) Receive Band (Rx)
LTE B2 1850 - 1910 MHz 1930 - 1990 MHz
LTE B4 1710 - 1755 MHz 2110 - 2155 MHz
LTE B5 824 - 849 MHz 869 - 894 MHz
6
