DSC LE2080 User Manual

Features
l 128-bit AES encryption via cellular and Ethernet/Internet
- NIST validation cert number 2645 (for models TL2803G(R)E/3G2080(R)E/TL280(R)E
- NIST validation cert number 4475 (for models TL280LE(R)/LE2080(R))
l Backup or primary cellular alarm communication.
l Automatically converts to 2G (EDGE/GPRS) if HSPA(3G) service is not available (2G not supported on European models
only).
l Automatically switches from LTE to HSPA(3G) service if LTE service is not available.
l Ethernet LAN/WAN 10/100 BASE-T (TL2803G(R)E, TL280(R)E, TL280LE(R) only).
l Fully redundant Ethernet/Internet and cellular dual-path alarm communication (TL2803G(R)E, TL280LE(R) only).
l Full event reporting to the central station.
l Individual Internet and/or cellular periodic test transmission.
l Integrated call routing.
l Visual Verification (Requires Sur-Gard System 5 Receiver)
l Remote firmware upgrade capability of the communicator and panel firmware via Ethernet and/or cellular.
l Panel remote uploading/downloading support via cellular and Ethernet/Internet.
l PC-LINK connection.
l Programmable labels.
l SIA and Contact ID (CID) formats supported.
l Signal strength and trouble display LEDs.
l Supervision heartbeats sent via cellular and Ethernet/Internet.
l Third-party integration over cellular/IP. The product supports third-party application via serial (R-models only), cellular
and Ethernet. Refer to third-party application documentation for more information.
NOTE: RS-232 connection is for supplementary use only and was not evaluated by UL/ULC.
Technical Specifications
The TL2803G(R)E/TL280LE(R) are also suitable to be used with a compatible control unit listed for dual line security trans-
mission when used in conjunction with a DACT or a Public Switched Data Network (PSDN) transmitter, where the PSDN
provides the line security and is the primary line. In this mode,alarm signals are to be sent simultaneously over both com-
munication methods.
EN50131-1 Installation Requirements
For EN50131-1 compliant installations, the following programming options shall be set as described. Supervision Heart-
beat (required for ATS4 and ATS5):
NOTE: The compatible receiver at ARC location shall have the supervision window programmed for 1800s (ATS4) or 180s
(ATS5) for the primary communications path, which can be Ethernet receiver 1 or cellular receiver 1, depending on
the product being installed.
l
[851][107] Set to 0087h (135s Heartbeat) for Ethernet Receiver 1
l
[851][207] Set to 0087h (135s Heartbeat) for Cellular Receiver 1
l
[851][100] Options 1 and 2 shall be enabled if using Ethernet Receiver 1 as the primary path
l
[851][200] Options 1 and 2 shall be enabled if using Cellular Receiver 1 as the primary path
Configuration of communication paths (all ATS classes)
l
[300][001] select option 02 for auto routing (this will allow transmission of the events over all available communication
paths in the system)
l
[380] enable option 5 (YES) for parallel transmission over all available communication paths (if redundant con-
figuration is desired)
l
[382] enable option 5 (YES) to enable Alternate communicator
l
[384] enable the desired back-up configuration (receiver 2 back-up for receiver 1 or receiver 3 back-up for receiver 1).
Ratings Compatibility
Table 6: Communicator Ratings
9
