DSC PC2585 - Page 45

41
PC2585 v 1.1R
[17] Maintenance Restoral Reporting Codes
Page 21
Low Battery Restore
AC Failure Restore
Bell Fuse Trouble Restore
Fire Trouble Restore
AUX Supply Trouble Restore
Telephone Line Monitor Trouble Restoral
Keypad Lockout Code
Test Transmission Code
[18] Zone Definitions
Page 22
NOTE: When defining zones, assign delay zones first to Zones 1, 2, 3 and so on. Then, assign the other zone
types to the remaining zones in any order desired.
Note that Tamper Alarms are always audible; refer to Section [25] Light 5.
t
When Section [26] Zone Light 1 is ON, Zone 7 will be a Fire Zone and the Zone Definition programmed in
Section [18] for Zone 7 will be ignored.
Default
0 0 Zone 1
0 1 Zone 2
0 1 Zone 3
0 1 Zone 4
0 1 Zone 5
0 1 Zone 6
0 1 Zone 7
t
0 1 Zone 8
First Digit Second Digit
0 = Audible 0 = Delay
1 = Silent 1 = Instant
2 = Chime Audible 2 = Interior
3 = Chime Silent 3 = Home Away
4 = 24-hour Bell
5 = 24-hour Bell/Buzzer
6 = 24-hour Buzzer
7 = Auxiliary Delay
8 = Interior Delay
[19] System Times
Page 23
Default
0 3 0 Entry Delay (seconds)
0 4 5 Exit Delay (seconds)
0 4 5 Auxiliary Entry Delay (seconds)
0 6 0 Auxiliary Exit Delay (seconds)
0 0 3 Bell Time-out (Valid entries are from 001 to 255 minutes)
0 3 0 AC Failure Reporting Delay (minutes)
0 5 0 Zone Loop Response Time (× 10 ms. Valid entries are from 010 to 255)
0 3 0 Test Transmission Interval (days)
[20] First System Option Code
Page 23
Default Zone Light ON Zone Light OFF
OFF Zone Light 1 Communicator disabled Communicator enabled
OFF Zone Light 2 Alternate dialing Standard dialing
OFF Zone Light 3 DTMF dialing Pulse dialing
OFF Zone Light 4 Pulse Dialing Make/Break Ratio: 40/60 Pulse Dialing Make/Break Ratio: 33/67
OFF Zone Light 5 1400Hz Radionics handshake 2300Hz Radionics handshake
OFF Zone Light 6
Not Used
ON Zone Light 7 Busy tone detection enabled Busy tone detection disabled
OFF Zone Light 8 Force Dialing enabled Force Dialing disabled
