SLICE User’s Manual July 2017
support.dtsweb.com 58 Version 1.0i
Either FullBridge or HalfBridge
The specified bridge resistance used during the shunt
check
The user provided description for the channel
The user provided description for the sensor; currently
the same as ChannelDescriptionString
The user requested full scale
The sensitivity of the sensor in either mv/V/EU or
mv/EU depending on ProportionalToExcitation
The requested filtering to apply to this channel. Stored
data is unfiltered, and this value must be used to apply
proper filtering. Typical values are "1650hz" for
CFC1000.
Indicates if the output of this sensor is proportional to
excitation. Used in conjunction with Sensitivity.
(Optional) Indicates if the data should be inverted
before presenting to the user. If missing, this attribute
is considered 'false'.
(Optional) Indicates if the data stored on disk is at a
lower sample rate than the original data collection. If
missing, this attribute is considered 'false'.
The user provided Engineering Units (EU) (e.g., mm, g,
or msec2)
The serial number of the sensor used with this channel
Applies to IEPE SLICE only.
For Bridge SLICE only. Indicates if the user requested
the channel be shunted during diagnostics.
Indicates if the user requested hardware offset
compensation be used during diagnostics
Identifies the type of software offset compensation that
should be used. If the value is "UsePreCalZero," then
the Pre Calibration zero value stored in the channel file
should be used. If the value is "AverageOverTime,"
then an average value computed from the channel data
should be used.
If ZeroMethod=AverageOverTime, this is the beginning
of the window to be used for computing the average
If ZeroMethod=AverageOverTime, this is the end of the
window to be used for computing the average
