Dual MXCP44 - Radio Specifications; Tuner and Speaker Specifications; General Unit and Power Specifications

13
MXCP44 OPERATION
Radio Specifications
Tuningrange: 87.5MHz-107.9MHz
Usablesensitivity: 10dBf
50dBquietingsensitivity: 25dBf
Stereoseparation@1kHz: >30dB
Frequencyresponse: 30Hz-18kHz
Tuningrange: 530kHz-1710kHz
Usablesensitivity: <36dB
Frequencyresponse: 80Hz-2kHz
OutsideDiameter:7.13"
MountingDepth:2.13"
MountingHeight:.87"
Cut-outDiameter:5.13"
FrequencyResponse:45Hz-15kHz
Sensitivity:88dB 1W/1M
Impedance:4 ohms
RMSPower: 20 Watts @ 1kHz
PeakPower:100 Watts @ 1kHz
Speakeroutputimpedance: 4~8 ohms
Lineoutputvoltage: 2 Volts RMS
Fuse:10 amp AGC
Dimensions: 7" x 2" x 5" (178 x 50 x 130 mm)
Designandspecificationssubjecttochangewithoutnotice.
FM Tuner
AM Tuner
Speakers
General
CEA-2006 Power Standard Specifications
(reference:14.4VDC+/-0.2V,20Hz~20kHz)
PowerOutput:18WattsRMSx4channelsat4ohmsand<1%THD+N
Signaltonoiseratio:70dBA(reference:1wattinto4ohms)
