Dual XDCPA10BT User Manual

6
XDCPA10BT INSTALLATION
Wiring Diagram - Inputs/Outputs
Note: When replacing a fuse, make sure to use the correct type and amperage. Using an incorrect fuse could cause damage. The unit uses (1) 15 amp ATC mini style fuse located on the power connector. Wiring Notes: Subwoofer output The Subwoofer preamp audio output (Blue jacket with Black RCA) is active in all audio modes. Rear camera input A rear view camera (not included) can be used with the Camera input.
CarPlay and
Android Auto
GRAY
BLACK
18PIN
BLUE
BLUE
RED
WHITE
RED
WHITE
YELLOW
RED
YELLOW
WHITE
GND
CAMERA12V
AVINR
AVINL
VIDEOIN
CAMERAIN
LINEOUTFRONTL
LINEOUTFRONTR
LINEOUTREARL
LINEOUTREARR
SUBWOOFER1
SUBWOOFER2
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
GRAY
RED
WHITE/BLACK
GRAY/BLACK
GREEN
GREEN/BLACK
VIOLET
VIOLET/BLACK
RED
BLACK
YELLOW
ORANGE
VIOLET/WHITE
BLUE
PINK
BLUE/WHITE
WHITE
GRAY
LEFT FRONT(-)
RIGHT FRONT (-)
LEFT REAR(+)
LEFT REAR(-)
RIGHT REAR(+)
RIGHT REAR(-)
CHASSIS GROUND(-)
BATTERY 12(+)
LLUMINATION(+)
REVERSE(+)
POWER ANTENNA (+)
PARKING BRAKE(-)
REMOTE TURN-ON(+)
LEFT FRONT(+)
RIGHT FRONT(+)
SWC INPUTGRAY(RED CAP)
IGNITION / 12V(+)
IGNITION /
ACC 12V(+)
GROUND(-)
BATTERY(+)
ILLUMINATION
REVERSE(+)
20PIN
SWCIN

Dual XDCPA10BT Specifications

General

Bluetooth	Yes
Touchscreen	Yes
USB Ports	1
Backup Camera Input	Yes
Apple CarPlay	No
Android Auto	Yes
Peak Power Output	50 watts x 4 channels
Power Output	50 watts x 4 channels
Auxiliary Input	Yes
Display Type	LCD
Remote Control	Yes
Screen Size	10.1 inches
Preamp Outputs	3 pairs (Front, Rear, Subwoofer)
RMS Power Output	16 watts
RCA Preamp Outputs	3 pairs (Front, Rear, Subwoofer)
