Dual XDMA6540 - Page 7

7
XDMA6540 OPERATION
Volume
Mute
Display
Select / Tag
Steering Wheel
Interface Input
Auxiliary Inputs
Reset
Setting the Clock
12/24-Hour Clock
General Operation
Adjustvolumeusingvolumeknob(00-46).
Press MUTEtosilencetheaudio.“MUTE”willflashin
thedisplay.PressMUTEagaintocancel.
Press DISPtotogglebetweenitemssuchasID3tag
songinformation,file/folderinformationortheclock.
PushthevolumeknobinwardtoactivatetheSELECT
function.Pushandholdthevolumeknobinwardto
activatetheTAGfunction.
Thesteeringwheelinterfaceinputlocatedontheback
oftheheadunitallowsconnectiontothePAC (Pacific
Accessory Corporation) SWI-PSinterfacemodule
(soldseparately).Visitwww.pac-audio.comfordetails.
Toconfiguresteeringwheelcontrols,followthe
instructionsprovidedwiththePAC SWI-PSinterface
module.Afterinstallingtheinterfacemodule,insert
themodule's3.5mmjackintotheportlabeled
"REMOTEIN"onthebackoftheheadunit.
TheXDMA6540featurestwoauxilaryinputs.Insert
a3.5mmconnectorinthefrontpanelAUXport,or
connectRCA-typecablesintotherearAUXport.Press
MODE UP/DOWNtoselectAuxFrontorAuxRear
modes.
PresstheRESETbutton,locatedbehindthefront
panel,toresettheunitbacktothefactorysettingsif
abnormaloperationoccurs.
Withtheuniton,pressandholdDISPuntiltheclock
beginstoflash,thenrelease.PressTUNE
nn
toadjustthehoursandTUNE
ll
toadjustthe
minutes. Press DISPmomentarilytosavetheselected
time.
Note:TheclockcanalsobesetintheGENERAL
menu.Seepage11fordetails.
Theclockwilldisplay12-hourAM/PMtimeinUSA
frequencyspacingmode(PM10
:
00).InEuropean
frequencyspacingmode,theclockwilldisplay
24-hourtime(22:00).
Note:24-hourtimeandEuropeanfrequencyspacing
arenotavailableiftheHDM90HDRadio™tunerare
connected.
