Key-On/Key-Off using the button on the Hands
free lock
with active key. Key-On can be performed by pressing
button (7) on the Hands free lock (1, Fig. 88) and with
the presence of the active key (3, Fig. 88).
Note
The active key (3) has a range of approx. 1.5 m
(59.06 in), therefore it must be located within this
range to be detected by the system.
Key-Off can be performed by pressing button (7) on
the Hands free lock (1, Fig. 88), also without the key
(3, Fig. 88).
Fig. 95
148
