Electric system
Basic electric items are:
Headlight:
LED low beam light type:
No. 4 LEDs (13.5V - 24.3W);
LED high beam light type:
No. 5 LEDs (13.5V - 18.9W):
LED parking light type:
No. 5 LEDs (13.5V - 6.2W).
Electrical controls on handlebars.
Turn indicators: front ones:
LED (13.5V - 4.7W).
Horn.
Stop light switches.
Sealed battery, 12V-10 Ah.
GENERATOR 14V-490W - 35A.
MASTER FUSE, protected by a 30A fuse, of the
Automotive type, not including ABS which has two
specific ones, located on solenoid starter, behind the
battery (C, Fig. 176).
Starter motor: 12V-0.7 kW.
Tail light, stop light and rear turn indicators:
parking light: (13.5V-0.3W);
stop light: LED (13.5V - 1.4W);
rear turn indicators: LED (13.5V - -2.06W).
Number plate light: LED (13.5V - 0.7W).
Note
For bulb replacement instructions, please see
the paragraph "Replacing the high and low beam
bulbs".
