Adjusting throttle control free play
The throttle grip in all steering positions must have 1.5
to 2.0 mm (0.06÷0.08 in) of free play, measured at the
outer edge of the twistgrip housing.
If necessary, adjust using the relevant adjusters (1
and 2) located on the steering tube on the right side of
the motorcycle.
Adjuster (1) is for throttle opening, while adjuster (2) is
for throttle closing.
Slip the rubber gaiters off the adjusters and loosen the
check nuts (3).
Adjust both adjusters by the same amount: turn
clockwise to increase free play and counter clockwise
to reduce free play.
When finished, tighten the lock nuts (3) and refit the
protection gaiters to the adjusters.
0.06÷0.08 in
1,5÷2 mm
Fig. 149
2
1
3
Fig. 150
