Ducati Diavel 2016 - Left-Hand Switch

Left-hand switch
1) Dip switch, two-position light selector switch:
(A) every time it is pressed down the light switches
from low beam ON to low beam and high beam
ON ;
(B) pushed to the side high beam flasher
(FLASH), "Start-Stop lap" function.
2) 3-position turn indicator switch
:
centre position = OFF;
position = left turn;
position
= right turn.
3) Turn indicator OFF, "Riding Mode" activation and
menu navigation button.
4) Button
= warning horn.
5) Navigation menu, display scroll, and TRIP1 and
TRIP2 reset button.
6) Navigation menu, display scroll button.
5
64
2
1
1
A
B
3
Fig. 102
154
