Error warnings
This function allows detecting any vehicle abnormal
behaviour. Instrument panel activates, in real time,
any vehicle abnormal behaviour (ERRORS).
Upon Key-On (once check routine is completed) one
or more "ERRORS" are displayed in red (if active, only).
As soon as one "error" is activated, the (red) indication
is clearly displayed (A) for 10 seconds, and it is then
minimised (B).
If several errors are present, they will be displayed in
"rolling" mode every 3 seconds; when one or more
errors referred to the engine control unit are
activated, the "Engine/Vehicle Diagnosis - EOBD"
warning light (C) will come on as well on handlebar
instrument panel. For any other types of errors, the
Generic Error warning light (D) on the instrument
panel on tank is also on.
Hereinafter is the table of the possible displayed
errors.
10355 16.3
3
TOT
CONS.AVG
KM/L
162 HIGH
GEAR
SPORT 03 DTC
10355
FREE
HANDS
GENERIC!
FREE
HANDS
GENERIC!
3
TOT
162 HIGH
GEAR
SPORT
03 DTC
Fig. 42
