Ducati Diavel 2016 - Function Buttons

Function buttons
Function buttons for the menus of the instrument
panel on tank.
1) CONTROL BUTTON.
Button used to display and set instrument panel
parameters with the position "
".
2) CONTROL BUTTON
Button used to display and set instrument panel
parameters with the position "
".
3) HIGH-BEAM FLASH BUTTON (FLASH)
The high-beam flash button may also be used for
LAP functions.
4) DISABLE (RESET) BUTTON
The turn indicators disable button may also be
used for the RESET/CONFIRM function of the
instrument panel and for enabling the "Riding
Mode".
2
3
4
1
Fig. 5
27
