Seat lock
Work latch (1) to remove the seat and access the
underseat compartment and reach any other device
under it.
Removing the seat
Insert the active or passive key in the lock (1), turn it
clockwise and simultaneously press down in the area
of the catch to help release the pin.
Pull the seat back to release it from the front catches.
Fig. 115
Fig. 116
166
