Rear left fuse box (A) key
Pos El. item Rat.
1 Throttle opening relay (ETV) 15 A
2 Injection relay 20 A
3 Key-sense 15 A
4 Engine control unit 10 A
5 Instrument panel 10 A
6 - -
7 - -
Rear right fuse box key (B)
Pos El. item Rat.
1 Diagnosis/Recharge 7.5 A
2 Navigator/Alarm 7.5 A
3 Black Box System (BBS) 15 A
4 Black Box System (BBS) KEY 10 A
5 Heated handgrips 5 A
6 - -
7 - -
