Instrument panel on tank
Instrument panel on tank consists of a colour TFT
display housed inside tank fairing and displays trip
information (set riding mode, odometer, fuel
consumption, average speed, etc.) as well as the
"setting" menus to be used to enable and adjust the
different functions.
10) GENERIC ERROR WARNING LIGHT (AMBER
YELLOW).
It turns on when there are any "vehicle" errors, i.e.
active errors triggered by any control unit other than
the engine control unit.
10355 16.3
3
TOT
CONS.AVG
KM/L
162 HIGH
GEAR
SPORT 03 DTC
10
Fig. 4
