Main components and
devices
Position on motorcycle (fig. 25)
1) Fuel tank filler cap
2) Passenger seat lock and helmet holder.
3) Document compartment lock.
4) Side stand.
5) Front fork adjusters.
6) Rear shock absorber adjusters.
7) Rear view mirrors.
8) Silencer and exhaust pipes.
9) Catalytic converter.
Warning
The exhaust system might be hot, even after engine is
switched off; take special care not to touch exhaust system
with any part of your body and do not park the motorcycle
next to inflammable material (wood, leaves etc.).
48
8
6
7
8
7
1
9
5
5
5
3 6 2
fig. 25
