Electrical system
The main components of the electrical system are:
Front headlight with two vertically arranged halogen lamps,
consisting of the following:
low beam unit H7 (12V-55W);
high beam unit H7 (12V-55W) for EU and UK - H9 (12V-65W)
for USA;
parking light 12V-6W.
Electrical controls on handlebars.
Turn signals, bulbs 12V-10W.
Horn
Brake light switches
Sealed battery 12V-10 Ah.
Alternator 12V-520W.
Electronic voltage regulator (rectifier), protected by a 30 A
fuse near the battery.
Starter motor, Denso, 12V-0.7 kW.
Tail light with double filament bulb 12V-5/21W for
brake and parking light; number plate light 12V-5W.
Notes
To replace the bulbs, see “Replacing bulbs” on
page 68.
