75
E
Unscrew the two self-tapping screws (3) securing the
shell (4) and the number plate light lens.
Remove the shell and the lens and change the number
plate light bulb (5) (fig. 77).
To change the brake light bulb, proceed as above and
also remove the brake light lens (6) from its support.
Push and twist the bulb (7) anti-clockwise to remove it
(fig. 78).
When refitting the lens (6) make sure that the tabs (B)
engage the slots in the support correctly.
4
5
4
3
fig. 77
6 7
B
fig. 78
