Ducati Multistrada 1200 - Front Half-Mudguard Kit

Front half-mudguard kit
Important
To fit the from semi-mudguard kit, ALWAYS
contact a Ducati Dealer or Authorised Service Centre.
Remove the pipe grommet (1) unscrewing the two
screws (2).
Position the front semi-mudguard kit (3) on the front
mudguard, housing the front brake pipe (4) and the
front phonic wheel cable (5) as shown in the figure
(Fig. 143).
Fasten tab (A) into slot on front mudguard (3).
1
2
Fig. 142
5
3
4A
5
4
Fig. 143
189
