Ducati Multistrada 1200 - Rear Long Mudguard Kit

Rear long mudguard kit
Important
To fit the long rear mudguard kit, ALWAYS
contact a Ducati Dealer or Authorised Service Centre.
Remove the rear mudguard (1) unscrewing the three
screws (2).
Position the long rear mudguard kit (3) on the
swingarm, starting the previously removed screws
(2).
Tighten the screws (2) to a torque of 5 Nm ± 10%.
2
1
2
Fig. 145
2
3
2
2
Fig. 146
191
