31. 12V electric panel
Label
Functions
Fuse code
Cut-off value
1
Navigation lights
FU15
5A
Steaming light
FU17
5A
Mooring light
FU16
5A
2
Auto-pilot
FU13
20A
3
Windlass control
FU14
10A
4
Deck light
FU8
10A
5
Instruments Navigation 1
FU7
10A
Instruments Navigation 2
FU9
20A
6
Audio
FU10
10A
Cabin USBs
FU12
10A
7
Saloon lights
FU4
15A
8
Water pump unit
FU5
10A
Shower pumps
FU6
10A
9
Interior fridge
FU11
10A
10
Cabin lights
FU2
15A
11
Bilge pump
FU1
15A
12
Cockpit fridge
FU3
10A
13
Display screen
FU18
2A
14
Source indicator
AC supply
15
Frontal USB socket
16
Navigation lights indicator
N.B.: depending on the type of boat or options, some features may not be active.
