Dufour 430 - Charging and Power System Diagram

ENGLISH 26-02-2019 Page 49/92 DUFOUR 430 GRAND LARGE
30. Charging and power system diagram
Label
.
Description
A
Windlass*
B
Windlass control* (remote)
C
Remote control relay*
D
8 A fuse – battery levels
E
Standard charger
E1
Windlass charger*
F
12V distribution panel
G
Single-pole 110 A circuit breaker*
H
Auxiliary batteries
I
160A fuse
J
Auxiliary batteries switch
K
5A fuse*
L
Alternator
M
Distributor
N
Starter
O
Engine battery
P
Engine battery isolator
Q
Windlass relay*
R
Bilge fan relay
S
5A fuse
T
Bilge fan
U
Windlass battery*
V
Windlass battery isolator*
B-
Terminal - (electrical panel)
T+
Terminal + (electrical panel)
Z-
Terminal - (technical area)
*
Option
