ENGLISH 26-02-2019 Page 53/92 DUFOUR 430 GRAND LARGE
32. Electrical panel rear wiring
Function switches
Position
Status
0
Disabled function
I
Forced Mode Function
II
Panel Mode Function – activated by the front
Label
Function
S1
Sailing Instruments
S2
Deck light
S3
Cockpit fridge
S4
Windlass control
S5
Audio / USB sockets
S6
Auto-pilot
S7
Interior fridge
S8
Cabin Lights
S9
Saloon Lights
S10
Navigation lights
S11
Bilge pump
S12
Water / shower pump unit
S13
Steaming light
S14
Mooring light
Connectors
K connectors
Label
Function
K1
AC Source Indicator – Shore Cable
K2
AC Source Indicator – Inverter
K3
AC Source Indicator – Generator
K4
Auxiliary and Optional battery installation voltage indicator
K5
Greywater holding tank level indicator
K6
CAN bus
K7
RS485 bus
K8
LIN bus
N.B.: depending on the type of boat or options, some features may not be active
