Dufour 430 - Gas System Diagram

ENGLISH 26-02-2019 Page 68/92 DUFOUR 430 GRAND LARGE
14 - Gas system diagram
A- 3-cabin front galley version
B- 4-cabin long galley version
Labe
l
Description
1
1.8 kg gas cylinder**
2
CE shut-off valve (Fr. or Ger.)
3
30mbar CE regulator valve (Fr. or Ger.) / pressure
gauge
4
Medium-length connecting hose
5
Spacer/tube 6 x 8
6
Watertight bulkhead fitting
7
PVC pipe
8
6 x 8 copper pipe
9
CE gas shut-off valve
10
Long connection hose
11
12
13
14
15
16
Cooker/Oven
Bulkhead gas locker
"T" gas connector*
Foldaway*
Split black sleeve
Gas foldaway hose *
*
Option
**
Not supplied
