Dufour 430 - Electrical Installation Diagram

ENGLISH 26-02-2019 Page 57/92 DUFOUR 430 GRAND LARGE
33. 12V electrical installation diagram
A- 3-cabin front galley version
B- 4-cabin long galley version
Label.
Description
1
Windlass*
2
Windlass relay*
3
Windlass remote control*
4
Navigation lights*
5
Fresh-water gauge
6
Reading lights
7
Water pump unit
8
Saloon speaker*
9
12V electric panel
10
11
Flexible LED switch
USB socket
12
Submersible bilge pump
13
Steaming light
14
Mooring light
15
Saloon downlight
16
Saloon downlight switch
17
Galley downlight switch
18
Galley downlights
19
Refrigeration unit
20
Shower waste pump
21
Windlass battery*
22
Windlass circuit breaker*
23
Bathroom downlight
24
Courtesy lights
25
Engine battery
26
Auxiliary batteries
27
Fuel gauge
28
Motor fan
29
Alternator
30
Engine and auxiliary battery isolator
31
Distributor
32
Starter
33
NA
34
Seawater pump
35
Exterior speaker*
36
Steering compass
37
Auto-pilot motor*
38
Courtesy lights switch
39
Seawater pump switch
*
Option
