Dufour 430 - 16- Freshwater System Diagram; Freshwater System Diagram

ENGLISH 26-02-2019 Page 74/92 DUFOUR 430 GRAND LARGE
16- Freshwater system diagram
A- 3-cabin front galley version
B- 4-cabin long galley version
Labe
l
Description
1
Filler deck plate
2
Filler hose
3
Vent
4
Vent hose
5
6
Fore water tank, 180 L
Stern water tank 250 L
7
Hot water pipe
8
Cold water pipe
9
Pressurized water pump unit
10
Fresh-water pump
11
Water heater
12
Head shower single-lever mixer tap
13
Galley single-lever mixer tap
14
Deck shower
15
Water tank selection valves
16
1/2" 3-way manifold
17
¾" male brass cap
18
1/4 turn FF 1/2” valve
19
¾" WX F connector
20
21
22
½" WX M connector
Seawater foot pump
Exterior sink tap*
*
OPTION
