Dufour 430 - Fuse Location Diagram; Fuse Diagram

ENGLISH 26-02-2019 Page 63/92 DUFOUR 430 GRAND LARGE
12- Fuse location diagram
A- 3-cabin front galley version
B- 4-cabin long galley version
Labe
l
Description
A
B
Zone A - 12V
Strip fuse 500A: optional bow thruster*
Differential circuit-breaker 110A: windlass*
Zone B - 12V
Blade fuse 1A: with gas solenoid valve*
Blade fuse 10A: heating option*
Blade fuse 5A: bow thruster option*
C
D
Blade fuse 10A: VHF option*
Blade fuse 30A: inverter option*
Resettable circuit breaker type C 16A: Electric toilets*
Zone C - 12V
Blade fuse 10A: bilge fan
Zone D - 12V
Strip fuse 160A: panel protection
E
Zone E - 220V General electrical box
16A/30mA differential circuit breaker: general protection
Phase/Neutral thermomagnetic circuit breaker 10A: water heater
protection
Phase/Neutral thermomagnetic circuit breaker 10A: charger protection
Phase/Neutral thermomagnetic circuit breaker 10A: 220V socket protection
F
Zone F - 12V
35A strip fuse: Electric aft gate*
G
Zone F: 220V
General circuit breaker: shore protection
*
OPTION
