Power Connectors – A – B – D
Label
Type
Definition
A1
Outlet
Water pump unit
A2
Inlet
AUXILIARY BATTERIES
A3
Outlet
Interior fridge
A4
Outlet
Bilge pump
A5
Inlet
AUXILIARY BATTERIES
A6
Outlet
Navigation Instruments 2
A7
Outlet
Shower pump
A8
Inlet
GND
A9
Outlet
Auto-pilot
B1
Outlet
Navigation lights
B2
Inlet
AUXILIARY BATTERIES
B3
Outlet
Saloon Lights
B4
Outlet
Mooring light
B5
Inlet
AUXILIARY BATTERIES
B6
Outlet
Cabin Lights
B7
Outlet
Steaming light
B8
Inlet
GND
B9
Outlet
Audio System
D1
Outlet
Deck light
D2
Inlet
AUXILIARY BATTERIES
D3
Outlet
Navigation Instruments 1
D4
Outlet
Cockpit Fridge
D5
Inlet
AUXILIARY BATTERIES
D6
Outlet
USB sockets
D7
Outlet
Windlass control
D8
Inlet
GND
D9 FREE
Signal Connectors – C
Label
Type
Value
Definition
C1
Inlet
-50 mV
100A shunt
C2
Inlet
+50 mV
100A shunt
C3
Inlet
0-180Ω
No.3 WATER Tank Level
C4
Inlet
0-180Ω
No.1 WATER Tank Level
C5
Inlet
��0-180Ω
No.1 FUEL Tank Level
C6
Inlet
0-14V
Engine Battery Voltage
C7
Inlet
0V
GND
C8
Inlet
0-180Ω
No.2 FUEL Tank Level
C9
Inlet
0-180Ω
No.2 WATER Tank Level
C10
Inlet
0-180Ω
No.1 Holding Tank Level
C11
Inlet
0-180Ω
No.2 Holding Tank Level
C12
Inlet
0-180Ω
No.3 Holding Tank Level
N.B.: depending on the type of boat or options, some features may not be active
