Installation and Operation of Flexible Batch Broiler
I. GENERAL INFORMATION
A. Batch Broiler Specications
FLEXIBLE BATCH BROILER SPECIFICATIONS
NATURAL GAS PROPANE
ALTITUDE (MAXIMUM) 2000 FT 607 m 2000 FT 607 m
GAS PIPE CONNECTION 3/4" F-NPT 3/4" F-NPT
INLET PRESSURE RANGE 7" – 12" W.C. 10" – 12” W.C.
MANIFOLD PRESSURE MANIFOLD PRESSURE
INFRARED BURNERS (TOP) 3.75" W.C. 0.93 kPa 8.0" W.C. 2.0kPa
LOWER BURNER 3.75" W.C. 0.93 kPa 8.0" W.C. 2.0kPa
TOTAL ENERGY RATE
94,000–100,000
BTU/HR
27.5 – 29.3
kW
94,000–100,000
BTU/HR
27.5 – 29.3
kW
BURNER ORIFICE SIZE BURNER ORIFICE SIZE
FRONT INFRARED BURNER #40 2.49mm #52 1.61mm
BACK INFRARED BURNER #36 2.70mm #51 1.70mm
LOWER BURNER #30 3.26mm #46 2.06mm
SHIPPING WEIGHT: 482 lbs (219 Kg)
SHIPPING DIMENSIONS: 47” x 34” x 68” (119.4 x 86.4 x 172.7 cm)
MODEL NUMBER ELECTRIC NATURAL & LP GAS
FBB-NO-120 120VAC,2A,60Hz 94,000–100,000BTU/HR
FBB-NC-120 120VAC,2A,60Hz 94,000–100,000BTU/HR
FBB-PO-120 120VAC,2A,60Hz 94,000–100,000BTU/HR
FBB-PC-120 120VAC,2A,60Hz 94,000–100,000BTU/HR
A-1.0 Model Number Key
FBB-X Y -120
X = N (NATURAL GAS) OR P (PROPANE / LP GAS)
Y = O (NO CATALYST) OR C (CATALYST)
120 = 120 VOLTS
