Duke READYFLEX RFDU 22 - RFDU Specification

RFDU Operator’s Manual
24
ELECTRICAL SPECIFICATION
(TOP AND BOTTOM HEAT)
DIMENSIONS:
Model
208/240 V -
60Hz-3~
400V -
50/60Hz-3N~
Height Width Depth (body only)
Amps Amps in. cm in. cm in. cm
RFDU-22
15.5/17.3 10 34.0 86.4 42.9 108.9 26.5 67.3
RFDU-23 15.5/17.3 11 34.0 86.4 62.0 157.5 26.5 67.3
Note: Units are eld wired. See page 7 for installation details
RFDU SPECIFICATIONS
62.00
34.02
26.53
RFDU-23 Shown Above
