Dunlop DL240B+ - TECHNICAL DATA

7
1 –TECHNICAL DATA
BASIC MODEL
Max. capacity
Kg
4000
Lifting time when loaded
s
40
Lowering time when loaded
s
40
Minimum height
mm
100
Lifting height
mm
2045
Distance between the columns mm 2800
Lift max. height
mm
3415
Three-phase electric motor
Volt-Hz-
Amp
230V/400V/50/60Hz -8.2
Three-phase motor power
kW/HP
3/4
Single-phase electric motor
Volt-Hz-
Amp
220V – 50Hz -19.5
220V – 60Hz -20.5
Single-phase motor power kW/HP 3/4
Max. operating hydraulic pressure
Bar
280
Controls circuit voltage
Volt
24
Total weight of lift
Kg
751 / 821
Package size (for shipment)
mm
2870x842x510
Recommended hydraulic oil
Tipo
46
Hydraulic system oil quantity Lt
9
Fixing to the floor with screw anchors N°10
HST3-M12x105 30/10
Weight electric / electronic materials
Kg
8
Motor weight
Kg
15
Average weighed sound level LpAm dB(A) 68,2
Average sound level at the operator's
workstation LpA
dB(A) 72
Acoustic power LwA
dB(A)
88,6
THE LIFTER IS SUPPLIED STANDARD WITH 220V-1PH-50HZ POWER SUPPLY. ONLY ON REQUEST,
IT CAN BE SUPPLIED WITH DIFFERENT ELECTRIC POWER SUPPLY.
