GF7 V1 waterproof plug and socket.
All UK Duplex steam machines have a plug and socket
connection (A) to the steam generator.
When using the machine in steam mode the plug and
socket must be connected and the fitting ring has to be
fully tightened
When changing to standard water tanks (removing steam generator) the cap (B) attached to
the steam tank socket on the machine must be fitted (screwed fully on and tightened).
Machine operation
The switch on the steam tank operates as an on/off switch for the steam, when in the on
position the steam generator only operates when the main handle is in the working position
i.e. the brushes are rotating.
The steam will take approximately 30 seconds to start,
before this there will be a small amount of water pumped
out of the steam generator, this is normal.
Remember a small amount of Hydroscale used at each
session will minimize scale build up.
When assembled the machine must look like the following drawing.
