STANDARD STEAM STEAM PLUS TEKNA
Figure 1.6
5.
Adjust the screw of the slide switch located underneath the lever (7) of the handgrip, at
the same time paying attention to the movement of the pistons (8) that allow the liquid to
exit from the tanks.
6.
Make sure that the pistons (8) remain flush with the side panel when the lever (7) is not
pulled down.
IMPORTANT!
If the pistons protrude it may not be possible to insert or
extract the tanks containing the liquid from their housings.
Use a screwdriver to adjust their position either inwards or outwards.
7
Figure
1.7
