Duplo DBM-120 Instruction Manual

12
5. BINDING
Setting saddle-stapling position
The position to be stapled is determined after setting the center of the paper on the unit.
Paper Width
(mm (inch))
Settable Staple Pitch (mm (inch))
108 (4.25)
Above 200 (7.87)
Setting side-stapling position
Staples within 6 mm (0.24") from the lead edge of the paper.
The position to be stapled is determined after setting the center of the paper on the unit.
Paper width
Staples
Direction
moved in
Staple pitch
Staples
Direction
moved in
Staple pitch
6 mm (0.24")
Paper width
160 (6.30)
Above 252 (9.92)
Paper Width
(mm (inch))
Settable Staple Pitch (mm (inch))
108 (4.25)
Above 200 (7.87)
160 (6.30)
Above 252 (9.92)
