1-3
Chapter 1 BEFORE OPERATION
2. Setting Up the Machine
2-1. Components
[1] [2] [3]
[4] [5]
[6]
[7]
220 to 240 V (For EU) 120 V (For North America)
No. Name Qty. Remark
[1] First folding plate 1 Attached to the right upper section on the operator's side.
[2] Second folding plate 1 Attached to the right lower section on the operator's side.
[3] Instruction manual 1 This manual
[4] Scale label 1 Used to measure non-standard size paper. Attach the scale.
[5] Guide plate unit 1 Used when folding B6 size thin paper (for EU) and small sized me-
dium thickness paper (for North America) into four.
[6] Cross folding lever 1 Used when cross folding paper.
[7] Power cord 1
To Next Page
